rear lights

Post by **alank950** » 09 Jul 2016, 18:50

Anyone know what the lower rear outside light is for ..''red'' ..Mine is staying on and I cannot locate what these are actually for?

thanks

Post by **kevtherev** » 09 Jul 2016, 19:10

VW have separate brake and side lights
Is this what you mean?

Post by **alank950** » 09 Jul 2016, 19:27

The rear light cluster bottom outside red lights are staying on.I am trying to find out what this light is for .This has only happened from yesterday ..Its a full light unit no separates .both near side and off side are on..1985 van
The light unit is amber,white ,red on tip
And bottom is three red lights running parallel

didn't understand this
VW have separate brake and side lights

Post by **alank950** » 09 Jul 2016, 20:01

Ok from what I have found out this is the brake light ..any ideas why the brake lights would be staying on?
.Just read on another thread it could be the brake light switch running into the master cylinder?
Will have a proper look tomorrow..is the master cylinder in the engine bay?

Post by **bigherb** » 10 Jul 2016, 06:12

alank950 wrote:Ok from what I have found out this is the brake light ..any ideas why the brake lights would be staying on?
.Just read on another thread it could be the brake light switch running into the master cylinder?
Will have a proper look tomorrow..is the master cylinder in the engine bay?

No it is above the pedals accessed by removing the instrument binnacle, there can be one or two switches.

Post by **alank950** » 10 Jul 2016, 07:29

Thanks.

.
should have known that anyhow as I had the instrument cover off before ..
