fixing points for 3/4 rock and roll bed?

[weerickyni]

hi, ive a van that has 3 anchor points with seatbelts fitted but how do i fix my rock and roll bed securly? it has two long metal bits out the back which i presume are for fitting it. i was just goin to get 2 steel L bits and weld them to the floor then put a bolt through them and the bars out the back. HELP!!!!! if anyone has a pic of a bed frame fitted it would be appreciated!! ive done searches and found nothin!.

[windysurfer]

The seats are currently out of mine being recovered so I can take some picture of how my hinges are fitted tomorrow ( so long as I'm home before it dark)if nobody has any handy

[weerickyni]

that would be great cheers!!!

[windysurfer]

Not the best piccies but it was dark when I arrived home.
I've just re-read your post and think my bed may be a different type
Anyhow heres the pictures

[andymacdonald30]

A few years ago I got some rock n roll seat brackets from JK and they came with fitting instructions
I seem to remember that the 2 arms at the back of the brackets had to be fixed to the firewall of the engine bay
But I recently got some from fleebay and they are only fitted to the woodwork of the seat base and to side of the kitchen unit
I found a long bolt abd fitted it to the seatbelt securing hole through the side of the seat base on the sliding door side

A bit of a struggle but trial and error got it sorted

I still have the bit of ply with the holes in if you need the measurments
Let me know and I will take a pic and some measurements

Andy
